The RC0603JR-070RL by YAGEO is a Zero Ohm Resistor, commonly referred to as a jumper, designed for surface mount applications. With a 0603 package size (1608 Metric), measuring 0.06 inches by 0.03 inches, it is compact and well-suited for space-constrained circuits. As a thick film resistor, it provides reliability in diverse electronic applications. The resistor has a power rating of 100 milliwatts (100 mW) and can handle a current of up to 1 ampere (1 A).

Primarily serving as a jumper, this component acts as a zero-ohm resistor, effectively connecting two points on a circuit board. This functionality aids in routing signals or bridging connections without introducing resistance. The RC0603JR-070RL is a Surface Mount Device (SMD), making it suitable for modern electronics with compact designs and surface mount assembly processes. Overall, it is a versatile and efficient component for circuitry requiring zero-ohm connections.

Features:

1. Primarily used as a jumper in electronic circuits.
2. Suitable for surface mount assembly processes.
3. Well-suited for space-constrained circuits.
4. Acts as a zero-ohm resistor, effectively connecting two points on a circuit board.
5. Efficient for circuitry requiring zero-ohm connections.

Package Includes:

1 x RC0603JR-070RL YAGEO Zero Ohm Resistor, Jumper, 0603 [1608 Metric], Thick Film, 100 mW, 1 A, Surface Mount Device
